Leeson
0.25HP 1PH 48Y 4P OAO 1625 PSC 460V AOL CF
Mfr # X420 | Wright’s # LSN X420
1/4HP Condenser Fan Motor, 1 Phase, 48Y Frame, 1625 RPM, 1 Speed, Permanent Split Capacitor, 460V, OAO Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # X420
Wright's # LSN X420
Country of Origin MEX
Specifications
C Dim 10.94"
Electrical Type Permanent Split Capacitor
Enclosure OAO
Full Load Efficiency 58
Frame 48Y
Frequency 60 Hz
HP 0.25 HP
HP2 1/4 HP
Insulation Class B
kW 0.19kW
Material Rolled Steel
Max Ambient 40°C
Mounting Type Round - Extended Studs
Number of Poles 4
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 1.0
Rated Voltage 460
Rotation Selective Counterclockwise
RPM 1625
Service Factor 1
Shaft Diameter 0.5"
Speed 1625
Starting Method
Description
Automatic reset thermal protector prevents overheating.
Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
