Leeson
1/8HP PSC 48Y 8P 825 115V AOL
Mfr # X261 | Wright’s # LSN X261
0.13HP 1 Phase, 48Y Frame, 825 RPM, 1 Speed, Permanent Split Capacitor, 115VV, Open Enclosed Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # X261
Wright's # LSN X261
Country of Origin MEX
Specifications
C Dim 10.09"
Electrical Type Permanent Split Capacitor
Enclosure Open Enclosed
Full Load Efficiency 53.3
Frame 48Y
Frequency 60
HP 0.13 HP
HP2 0.13 HP
Insulation Class B
kW 0.09kW
Material Rolled Steel
Max Ambient 40°C
Mounting Type Round
Number of Poles 8
Number of Speeds 1
Overload Protection AOL
Phase 1
Rated Current 2.1
Rated Voltage 115V
Rotation Selective Counterclockwise
RPM 825
Service Factor 1
Shaft Diameter 0.5"
Speed 825
Starting Method
