Leeson
0.14HP 1PH 48MZ 2P SE 3450 SpP 115V MOL
Mfr # O100 | Wright’s # LSN O100
1/7HP Fan & Blower Motor, 1 Phase, 48MZ Frame, 3450 RPM, 1 Speed, Split Phase, 115V, SE Enclosure, Manual Overload Protection
$160.96
Product Information
Brand Leeson
Mfr # O100
Wright's # LSN O100
Country of Origin MEX
Specifications
C Dim 7.7"
Electrical Type Split Phase
Enclosure SE
Full Load Efficiency 46.5
Frame 48MZ
Frequency 60 Hz
HP 0.14 HP
HP2 1/7 HP
Insulation Class B
kW 0.11kW
Material Rolled Steel
Max Ambient 40°C
Mounting Type Round
Number of Poles 2
Number of Speeds 1
Overload Protection Manual
Phase 1
Rated Current 2.3
Rated Voltage 115
Rotation Selective Clockwise
RPM 3450
Service Factor 1
Shaft Diameter 0.5"
Speed 3450
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use.
Double shielded ball bearings provide longer service life.
Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
Various mounting configurations (as noted).
