Leeson
2HP 3PH 56H ODP 1800 208-230/460V AOL
Mfr # K1418 | Wright’s # LSN K1418
2HP Fan & Blower Motor, 3 Phase, 56H Frame, 1725 RPM, 1 Speed, Three Phase, 208-230/460V, DP Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
K1418
Wright's #
LSN K1418
Country of Origin
MEX
Specifications
C Dim
13.96"
Electrical Type
Three Phase
Enclosure
DP
Full Load Efficiency
81.8
Frame
56H
Frequency
60 Hz
HP
2 HP
HP2
2 HP
Insulation Class
B
kW
1.5kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
3
Rated Current
6.2-6.0,3.0
Rated Voltage
208-230/460
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.15
Shaft Diameter
0.63"
Speed
1725
