Leeson
0.33HP 3PH 56C 4P TENV 1725 208-230/460V WB
Mfr # G580 | Wright’s # LSN G580
1/3HP General Purpose Motor, 3 Phase, 56C Frame, 1725 & 1425 RPM, 1 Speed, Squirrel Cage Inverter Rated, 208-230/460V, TENV Enclosure
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
G580
Wright's #
LSN G580
Country of Origin
MEX
Specifications
C Dim
9.93"
Electrical Type
Squirrel Cage Inverter Rated
Enclosure
TENV
Full Load Efficiency
68
Frame
56C
Frequency
60 Hz
HP
0.33 HP
HP2
1/3 HP
Insulation Class
F
kW
0.25kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Bolt-on Base
Number of Poles
4
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
1.8-1.6/.8 & 1.5/.75
Rated Voltage
208-230/460
Rotation
Reversible
RPM
1725
Service Factor
1.15
Shaft Diameter
0.625"
Speed
1725 & 1425
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Heavy-duty, rolled steel construction ensures motor durability.
Permanently lubricated sealed bearings extend the lifetime of the motor.
Suitable for belt-driven or fan-on-shaft applications.
