Leeson
1.5HP 3PH 56 ODP 1800 208-230/460V
Mfr # G122 | Wright’s # LSN G122
1-1/2HP Fan & Blower Motor, 3 Phase, 56 Frame, 1725 & 1425 RPM, 1 Speed, Squirrel Cage Induction Run, 208-230/460V, DP Enclosure
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # G122
Wright's # LSN G122
Country of Origin MEX
Specifications
C Dim 11.35"
Electrical Type Squirrel Cage Induction Run
Enclosure DP
Full Load Efficiency 80
Frame 56
Frequency 60 Hz
HP 1.5 HP
HP2 1-1/2 HP
Insulation Class B
kW 1.1kW
Material Rolled Steel
Max Ambient 40°C
Mounting Type Resilient Base
Number of Poles 4
Number of Speeds 1
Overload Protection No Protection
Phase 3
Rated Current 4.8-4.8/2.4 & 4.2/2.1
Rated Voltage 208-230/460
Rotation Reversible
RPM 1725
Service Factor 1.15
Shaft Diameter 0.625"
Speed 1725 & 1425
Starting Method
