Leeson
1.5HP 1PH 56H ODP 1800 115/208-230V AOL
Mfr # C186A | Wright’s # LSN C186A
1.50HP General Purpose Motor, 1 Phase, 56H Frame, 1725 RPM, 1 Speed, Capacitor Start Capacitor Run, 115/208-230VV, Drip Proof Enclosure, Automatic Overload Protection
$561.48
Product Information
Brand
Leeson
Mfr #
C186A
Wright's #
LSN C186A
Country of Origin
MEX
Specifications
C Dim
13.99"
Electrical Type
Capacitor Start Capacitor Run
Enclosure
Drip Proof
Full Load Efficiency
83.8
Frame
56H
Frequency
60
HP
1.5 HP
HP2
1.50 HP
Insulation Class
B
kW
1.1kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Rigid Base
Number of Poles
4
Number of Speeds
1
Overload Protection
AOL
Phase
1
Rated Current
12.6/6.4-6.3
Rated Voltage
115/208-230V
Rotation
Selective Counterclockwise
RPM
1725
Service Factor
1.15
Shaft Diameter
0.625"
Speed
1725
Starting Method
