Leeson
1.50HP 3PH 143TC 4P TEFC 1750 230/460V WB SS
Mfr # 122221.00 | Wright’s # LSN 122221.00
1-1/2HP Painted Epoxy Coated Washdown Motor, 3 Phase, 143TC Frame, 1750 & 1450 RPM, 1 Speed, Squirrel Cage Inverter Rated, 230/460V, TEFC Enclosure
$638.32
Product Information
Brand
Leeson
Mfr #
122221.00
Wright's #
LSN 122221.00
Country of Origin
USA
Specifications
C Dim
12.75"
Electrical Type
Squirrel Cage Inverter Rated
Enclosure
TEFC
Full Load Efficiency
86.5
Frame
143TC
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
F
kW
1.1kW
Material
Stainless Steel
Max Ambient
40°C
Mounting Type
Rigid Base
Number of Poles
4
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
4.8/2.4 & 3.6/1.8
Rated Voltage
230/460
Rotation
Reversible
RPM
1750
Service Factor
1.15
Shaft Diameter
0.875"
Speed
1750 & 1450
Starting Method
Description
Full stainless steel exterior promotes resistance to water and chemical corrosion.
Double sealed bearings extend the lifetime of the motor by combating early signs of bearing failure.
Stainless steel output shaft seals protect against external contaminants.
Insulation systems deliver superior protection against voltage spikes.
