Leeson
1.50HP 3PH 143TC 2P TEFC 3490 208-230/460V NB SS
Mfr # 122207.00 | Wright’s # LSN 122207.00
1-1/2HP Painted Epoxy Coated Washdown Motor, 3 Phase, 143TC Frame, 3490 & 2890 RPM, 1 Speed, Squirrel Cage Inverter Rated, 208-230/460V, TEFC Enclosure
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
122207.00
Wright's #
LSN 122207.00
Country of Origin
USA
Specifications
C Dim
12"
Electrical Type
Squirrel Cage Inverter Rated
Enclosure
TEFC
Full Load Efficiency
84
Frame
143TC
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
F
kW
1.1kW
Material
Stainless Steel
Max Ambient
40°C
Mounting Type
Round
Number of Poles
2
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
4.4-4/2 & 3.6/1.8
Rated Voltage
208-230/460
Rotation
Reversible
RPM
3490
Service Factor
1.15
Shaft Diameter
0.875"
Speed
3490 & 2890
Starting Method
Description
Exterior 300-series stainless steel resists corrosion and maintains strength for reliable operation.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
All motor sealing components are Viton® for superior chemical resistance.
Conduit box mounting system provides optimum seal and protection (when present in motor design).
