Fasco
1/100HP ShP 3.3″ 1085 CCWSE 115V
Mfr # D1155 | Wright’s # FAS D1155
1/100HP OEM Replacement Motor, 1 Phase, 3.3″ Frame, 1085 RPM, 1 Speed, Shaded Pole, 115V, TE Enclosure
$102.91
Product Information
Brand
Fasco
Mfr #
D1155
Wright's #
FAS D1155
Country of Origin
MEX
Specifications
C Dim
3.63"
Electrical Type
Shaded Pole
Enclosure
TE
Frame
3.3"
Frequency
60 Hz
HP
0.01 HP
HP2
1/100 HP
Insulation Class
B
kW
0.01kW
Material
Steel
Max Ambient
40°C
Number of Poles
6
Number of Speeds
1
Overload Protection
Thermally Protected
Phase
1
Rated Current
0.5
Rated Voltage
115
Rotation
Counterclockwise Shaft End
RPM
1085
Service Factor
1
Shaft Diameter
0.25"
Starting Method
Description
OEM Direct Replacement Motor
3.3″ Diameter
Shaded Pole
Thermally Protected
Totally Enclosed Air Over
Class B Insulation, 40°C Ambient
Sleeve Bearing
1/4″ Diameter Shaft with Flatϲ” Leads with PIN Terminals
Extended Studs Lead End
120V
