Century
1/4HP PSC 48Y TE 1075 REV 460V 5uF CF
Mfr # 788A | Wright’s # CEN 788A
1/4HP Condenser Fan Motor, 1 Phase, 48Y Frame, 1075 RPM, 1 Speed, Permanent Split Capacitor, 460V, TEAO Enclosure
$300.48
Product Information
Brand
Century
Mfr #
788A
Wright's #
CEN 788A
Country of Origin
IND
Specifications
C Dim
11.05"
Electrical Type
Permanent Split Capacitor
Enclosure
TEAO
Full Load Efficiency
66
Frame
48Y
Frequency
60 Hz
HP
0.25 HP
HP2
1/4 HP
Insulation Class
B
kW
0.19kW
Material
Rolled Steel
Max Ambient
60°C
Number of Poles
6
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
0.75
Rated Voltage
460
Rotation
Reversible
RPM
1075
Service Factor
1
Shaft Diameter
0.5"
Speed
1075
Starting Method
Description
Condenser Fan – Heat Pump – Refrigeration Motor
5.6″ Diameter – 48 Frame
Permanent Split Capacitor (PSC); Capacitor Required: 7.5 Mfd-370 Volts (Not Supplied with Motor)
Thermally Protected
Totally Enclosed Air over
Class B Insulation, 60°C Ambient
Ball Bearing
1/2″ Diameter Shaft with FlatЂ” Leads
Extended Studs Shaft End
1/4HP Condenser Fan Motor, 1 Phase, 48Y Frame, 1075 RPM, 1 Speed, Permanent Split Capacitor, 460V, TEAO Enclosure
