WEG
1.5HP 3PH 143TC 2P TEFC 3600 208-230/460V WB RS
Mfr # 00156ET3E143TC-S | Wright’s # WEG 00156ET3E143TC-S
1.5HP General Purpose Motor, 3 Phase, 143TC Frame, 3600 RPM, 208-230/460V, TEFC Enclosure
Contact Us For Pricing
Product Information
Brand WEG
Mfr # 00156ET3E143TC-S
Wright's # WEG 00156ET3E143TC-S
Country of Origin MEX
Specifications
C Dim 13.189"
Efficiency NEMA Premium®
Enclosure TEFC
Frame 143TC
HP 1.5 HP
HP2 1-1/2 HP
kW 1.1kW
Material Rolled Steel
Number of Poles 2
Phase 3
Rated Current 1.9
Rated Voltage 208-230/460
RPM 3600
Description
All Cast Iron Construction, including Terminal Box and Fan Cover. Solid feet for reduced vibration levels and impact absorption. Optimized ventilation system for cooler operation and extended life. High Grade FC200 cast iron provides superior mechanical strength and heat dissipation. Four Bolt Conduit Cover with glued Neoprene Gasket. Impregnation Resin and magnet wire are insulation class H.
