7.5HP 1PH 184T 3600 ODP 230V
US Motors

7.5HP 1PH 184T 3600 ODP 230V

Mfr # D7C1K | Wright’s # USM D7C1K

7-1/2HP General Purpose Motor, 1 Phase, 184T Frame, 2 Poles, 3490 RPM, ODP Enclosure, 230V

$638.59

Product Information

Brand US Motors
Mfr # D7C1K
Wright's # USM D7C1K
Country of Origin MEX

Specifications

C Dim 16.3"
Electrical Type Capacitor Start
Enclosure ODP
Frame 184T
Frequency 60 Hz
HP 7.5 HP
HP2 7-1/2 HP
Insulation Class F
kW 5.59kW
Max Ambient 40°C
Mounting Type RIGID BASE
Number of Poles 2
Number of Speeds 1
Overload Protection None
Phase 1
Rated Current 30.0
Rated Voltage 230V
RPM 3490
Service Factor 1.15
