US Motors
1.5HP 1PH 145T 1800 ODP 115/208-230V
Mfr # D32C2J14 | Wright’s # USM D32C2J14
1-1/2HP General Purpose Motor, 1 Phase, 145T Frame, 4 Poles, 1725 RPM, ODP Enclosure, 115/208-230V
$576.65
Product Information
Brand
US Motors
Mfr #
D32C2J14
Wright's #
USM D32C2J14
Country of Origin
MEX
Specifications
C Dim
13.3"
Electrical Type
Capacitor Start
Enclosure
ODP
Frame
145T
Frequency
60Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
B
kW
1.12kW
Max Ambient
40°C
Mounting Type
RIGID BASE
Number of Poles
4
Number of Speeds
1
Overload Protection
None
Phase
1
Rated Current
19.2/10.0-9.6
Rated Voltage
115/208-230V
RPM
1725
Service Factor
1.15
