Marathon
1.5HP 3PH 145T 4P ODP 1750 230/460V TS WB
Mfr # U759 | Wright’s # MAR U759
Contact Us For Pricing
Product Information
Brand
Marathon
Sub-Brand
XRI® General Purpose
Mfr #
U759
Wright's #
MAR U759
Country of Origin
USA
Specifications
C Dim
12.62"
Electrical Type
Squirrel Cage Inverter Rated
Enclosure
ODP
Full Load Efficiency
86.5
Frame
145T
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
F
kW
1.1kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Rigid Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Thermostat
Phase
3
Rated Current
4.8/2.4 & 3.6/1.8
Rated Voltage
230/460
Rotation
Reversible
RPM
1750
Service Factor
1.15
Shaft Diameter
0.875"
Speed
1750 & 1450
Starting Method
