Leeson
0.75HP 1PH 48Y 6P TEAO 1075 PSC 460V AOL CF
Mfr # X459 | Wright’s # LSN X459
3/4HP Condenser Fan Motor, 1 Phase, 48Y Frame, 1075 RPM, 1 Speed, Permanent Split Capacitor, 460V, TEAO Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
X459
Wright's #
LSN X459
Country of Origin
MEX
Specifications
C Dim
12.5"
Electrical Type
Permanent Split Capacitor
Enclosure
TEAO
Full Load Efficiency
68
Frame
48Y
Frequency
60 Hz
HP
0.75 HP
HP2
3/4 HP
Insulation Class
B
kW
0.56kW
Material
Rolled Steel
Max Ambient
60°C
Mounting Type
Round - Extended Studs
Number of Poles
6
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
2.1
Rated Voltage
460
Rotation
Selective Counterclockwise
RPM
1075
Service Factor
1
Shaft Diameter
0.5"
Speed
1075
Starting Method
Description
Automatic reset thermal protector prevents overheating.
Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
