Leeson
0.33HP 1PH 48Z 4P TENV 1725 SpP 115V AOL Farm
Mfr # X1904 | Wright’s # LSN X1904
1/3HP Farm Duty Motor, 1 Phase, 48Z Frame, 1725 RPM, 1 Speed, Split Phase, 115V, TENV Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
X1904
Wright's #
LSN X1904
Country of Origin
MEX
Specifications
C Dim
9.93"
Electrical Type
Split Phase
Enclosure
TENV
Full Load Efficiency
60.5
Frame
48Z
Frequency
60 Hz
HP
0.33 HP
HP2
1/3 HP
Insulation Class
B
kW
0.25kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
6.2
Rated Voltage
115
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.35
Shaft Diameter
0.5"
Speed
1725
Starting Method
Description
Double-shielded bearings extend the service life of the motor.
EXXON® Polyrex® EM Grease supports extreme temperatures between -20°F(-29 ˚ C) and +350°F(+177˚C).
Shaft flingers protect bearings from damage caused by dirt and rain.
Condensation drains allow the motor to expel and drain built-up moisture.
