Leeson
63D IP54 3000 180V DC
Mfr # M1130143.00 | Wright’s # LSN M1130143.00
HP Phase, 63D Frame, 3000 RPM, Speed, Three Phase, 180V, IP54 Enclosure
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # M1130143.00
Wright's # LSN M1130143.00
Country of Origin USA
Specifications
C Dim 9.5"
Electrical Type Three Phase
Enclosure IP54
Full Load Efficiency 75.8
Frame 63D
Insulation Class F
kW 0.37kW
Max Ambient 40°C
Mounting Type B14
Overload Protection No Protection
Rated Current 2.4
Rated Voltage 180
Rotation Reversible
RPM 3000
Service Factor 1
Shaft Diameter 0.437"
Speed 3000
Description
Cast aluminum conduit box
Terminal board provided for connections
All metric fasteners
Easy brush access for field service
Oversize brushes for extended life
High strength rolled steel frame
Die cast aluminum endshields with steel bearing inserts
Permanently lubricated sealed ball bearings
Reversible rotation; Simple 2 lead connection; Convenient wiring access
