Leeson
0.06HP 25 TENV 42 90V DC Gear
Mfr # M1115018.00 | Wright’s # LSN M1115018.00
1/15HP Right Angle DC Gear Motor, Phase, 25 Frame, 42 RPM, Speed, Three Phase, 90V, TENV Enclosure
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # M1115018.00
Wright's # LSN M1115018.00
Country of Origin USA
Specifications
C Dim 8.8"
Electrical Type Three Phase
Enclosure TENV
Full Load Efficiency 18.2
Frame 25
HP 0.06 HP
HP2 1/15 HP
Insulation Class H
kW 0.04kW
Max Ambient 40°C
Mounting Type Special
Overload Protection No Protection
Rated Current 0.90
Rated Voltage 90
Rotation Reversible
RPM 42
Service Factor 1
Shaft Diameter 0.5"
Speed 42
Description
Precision machined aluminum gear housing.
Output shaft is field interchangeable from left hand to right hand style by re-assembly.
Performance matched for continuous duty service.
Lubrication is permanent semi-fluid grease, reducing possibility of leakage.
