Leeson
0.50HP 3PH 56 4P DP 1725 208-230/460V
Mfr # K381 | Wright’s # LSN K381
1/2HP Fan & Blower Motor, 3 Phase, 56 Frame, 1725 RPM, 1 Speed, Three Phase, 208-230/460V, DP Enclosure
$268.98
Product Information
Brand
Leeson
Mfr #
K381
Wright's #
LSN K381
Country of Origin
MEX
Specifications
C Dim
10.05"
Electrical Type
Three Phase
Enclosure
DP
Full Load Efficiency
78.7
Frame
56
Frequency
60 Hz
HP
0.5 HP
HP2
1/2 HP
Insulation Class
B
kW
0.37kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
2.3-2.2,1.1
Rated Voltage
208-230/460
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.25
Shaft Diameter
0.63"
Speed
1725
Description
Automatic reset thermal protector prevents overheating.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
