Leeson
0.75HP 3PH 56 4P DP 1725 208-230/460V
Mfr # K277 | Wright’s # LSN K277
3/4HP Fan & Blower Motor, 3 Phase, 56 Frame, 1725 RPM, 1 Speed, Three Phase, 208-230/460V, DP Enclosure
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
K277
Wright's #
LSN K277
Country of Origin
MEX
Specifications
C Dim
10.88"
Electrical Type
Three Phase
Enclosure
DP
Full Load Efficiency
74
Frame
56
Frequency
60 Hz
HP
0.75 HP
HP2
3/4 HP
Insulation Class
B
kW
0.56kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
3.3-3.0,1.5
Rated Voltage
208-230/460
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.25
Shaft Diameter
0.63"
Speed
1725
Description
Automatic reset thermal protector prevents overheating.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
