Leeson
1.50HP 3PH 56J 2P DP 3450 208-230/460V
Mfr # K223 | Wright’s # LSN K223
1-1/2HP General Purpose Pump Motor, 3 Phase, 56J Frame, 3450 RPM, 1 Speed, Three Phase, 208-230/460V, DP Enclosure
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
K223
Wright's #
LSN K223
Country of Origin
MEX
Specifications
C Dim
11.24"
Electrical Type
Three Phase
Enclosure
DP
Full Load Efficiency
77
Frame
56J
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
B
kW
1.1kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Round
Number of Poles
2
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
5.0-4.8,2.4
Rated Voltage
208-230/460
Rotation
Counterclockwise/Clockwise
RPM
3450
Service Factor
1.3
Shaft Diameter
0.63"
Speed
3450
Description
Double sealed ball bearings, mechanically locked on shaft end
Continuous Duty
Nameplated 60/50 hertz, 190/380 volts at next lower HP
56C = carbon steel shaft with key
56J = 416 stainless steel threaded shaft with slinger
Drip cover not included.
Connected for CW rotation facing opposite shaft end. Reversible by reconnection of leads
