Leeson
1.50HP 3PH 56C 2P DP 3450 208-230/460V NB
Mfr # K222 | Wright’s # LSN K222
1-1/2HP Fan & Blower Motor, 3 Phase, 56C Frame, 3450 RPM, 1 Speed, Three Phase, 208-230/460V, DP Enclosure
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
K222
Wright's #
LSN K222
Country of Origin
MEX
Specifications
C Dim
10.73"
Electrical Type
Three Phase
Enclosure
DP
Full Load Efficiency
77
Frame
56C
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
B
kW
1.1kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Round
Number of Poles
2
Number of Speeds
1
Overload Protection
No Protection
Phase
3
Rated Current
5.0-4.8,2.4
Rated Voltage
208-230/460
Rotation
Counterclockwise/Clockwise
RPM
3450
Service Factor
1.3
Shaft Diameter
0.63"
Speed
3450
Description
UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Double-shielded ball bearings provide longer service life.
Continuous or continuous air over duty design allows consistent operation at the rated power (as noted).
Various mounting configurations (as noted).
