Leeson
0.33HP 1PH 56C 2P DP 3450 115/230V AOL NB
Mfr # J1025 | Wright’s # LSN J1025
1/25HP Fan & Blower Motor, 1 Phase, 56C Frame, 3450 RPM, 1 Speed, Capacitor Start Induction Run, 115/230V, DP Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand Leeson
Mfr # J1025
Wright's # LSN J1025
Country of Origin MEX
Specifications
C Dim 10.71"
Electrical Type Capacitor Start Induction Run
Enclosure DP
Full Load Efficiency 56.6
Frame 56C
Frequency 60 Hz
HP 0.33 HP
HP2 1/25 HP
Insulation Class B
kW 0.25kW
Material Rolled Steel
Max Ambient 40°C
Mounting Type Round
Number of Poles 2
Number of Speeds 1
Overload Protection Automatic
Phase 1
Rated Current 6.4,3.2
Rated Voltage 115/230
Rotation Clockwise/Counterclockwise
RPM 3450
Service Factor 1.75
Shaft Diameter 0.63"
Speed 3450
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use.
Double shielded ball bearings provide longer service life.
Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
Various mounting configurations (as noted).
