Leeson
0.33HP 1PH 56CZ 4P DP 1725 SpP 115V AOL NB
Mfr # H218 | Wright’s # LSN H218
1/3HP Fan & Blower Motor, 1 Phase, 56CZ Frame, 1725 RPM, 1 Speed, Split Phase, 115V, DP Enclosure, Automatic Overload Protection
$352.63
Product Information
Brand
Leeson
Mfr #
H218
Wright's #
LSN H218
Country of Origin
MEX
Specifications
C Dim
10.25"
Electrical Type
Split Phase
Enclosure
DP
Full Load Efficiency
57.5
Frame
56CZ
Frequency
60 Hz
HP
0.33 HP
HP2
1/3 HP
Insulation Class
B
kW
0.25kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Round
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
6.6
Rated Voltage
115
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.35
Shaft Diameter
0.63"
Speed
1725
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use.
Double shielded ball bearings provide longer service life.
Continuous or continuous air over duty design allows consistent operation at the rated power(as noted).
Various mounting configurations (as noted).
