Leeson
0.75HP 1PH 56C 4P TEFC 1725 115/208-230V WB
Mfr # G572 | Wright’s # LSN G572
3/4HP General Purpose Motor, 1 Phase, 56C Frame, 1725 & 1425 RPM, 1 Speed, Capacitor Start Induction Run, 115/208-230V, TEFC Enclosure
$516.02
Product Information
Brand
Leeson
Mfr #
G572
Wright's #
LSN G572
Country of Origin
MEX
Specifications
C Dim
12.31"
Electrical Type
Capacitor Start Induction Run
Enclosure
TEFC
Full Load Efficiency
70.5
Frame
56C
Frequency
60 Hz
HP
0.75 HP
HP2
3/4 HP
Insulation Class
B
kW
0.56kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Bolt-on Base
Number of Poles
4
Number of Speeds
1
Overload Protection
No Protection
Phase
1
Rated Current
11/5.4-5.5 & 11.4/5.7
Rated Voltage
115/208-230
Rotation
Selective Counterclockwise
RPM
1725
Service Factor
1.15
Shaft Diameter
0.625"
Speed
1725 & 1425
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Continuous duty cycle design allows maximum operation at the rated power. specifications
Heavy-duty, rolled steel construction ensures motor durability.
Permanently lubricated sealed bearings extend the lifetime of the motor.
Capacitor start design optimizes motor torque and efficiency performance.
