Leeson
3HP 3PH 56HZ 4P DP 1725 208-230/460V AOL
Mfr # G145 | Wright’s # LSN G145
3HP Fan & Blower Motor, 3 Phase, 56HZ (56H, 143T, 145T Combination Base) Frame, 1725 & 1425 RPM, 1 Speed, Squirrel Cage Induction Run, 208-230/460V, DP Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
G145
Wright's #
LSN G145
Country of Origin
MEX
Specifications
C Dim
14.72"
Electrical Type
Squirrel Cage Induction Run
Enclosure
DP
Full Load Efficiency
84
Frame
56HZ
Frequency
60 Hz
HP
3 HP
HP2
3 HP
Insulation Class
B
kW
2.2kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
3
Rated Current
9.2-8.6/4.3 & 7.2/3.6-3.6
Rated Voltage
208-230/460
Rotation
Reversible
RPM
1725
Service Factor
1.15
Shaft Diameter
0.625"
Speed
1725 & 1425
Starting Method
Description
Automatic reset thermal protector prevents overheating.
Patented MAXGuard® insulation system offers superior protection for use with a variable frequency drive.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
Ambient temperature up to 70°C allows for consistent operation in a range of environments and applications.
Vertical/horizontal mounting for proper placement of the fan within airflow.
