Leeson
1/2HP 3PH 56 ODP 1800 208-230/460V BM
Mfr # G140 | Wright’s # LSN G140
0.50 & 0.33HP Fan & Blower Motor, 3 Phase, 56 Frame, 1725 & 1425 RPM, 1 Speed, Squirrel Cage Induction Run, 208-230/460VV, Drip Proof Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
G140
Wright's #
LSN G140
Country of Origin
MEX
Specifications
C Dim
10.85"
Electrical Type
Squirrel Cage Induction Run
Enclosure
Drip Proof
Full Load Efficiency
68
Frame
56
Frequency
60
HP
0.5 HP
HP2
0.50 & 0.33 HP
Insulation Class
B
kW
0.37kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
AOL
Phase
3
Rated Current
2.2-2.4/1.2 & 2.2/1.1-1.1
Rated Voltage
208-230/460V
Rotation
Reversible
RPM
1725
Service Factor
1.25
Shaft Diameter
0.625"
Speed
1725 & 1425
Starting Method
