Leeson
0.33HP 1PH 56 4P DP 1725 115/208-230V AOL
Mfr # C216 | Wright’s # LSN C216
1/3HP General Purpose Motor, 1 Phase, 56 Frame, 1725/1425 RPM, 1 Speed, Capacitor Start Induction Run, 115/208-230V, DP Enclosure, Automatic Overload Protection
$265.48
Product Information
Brand
Leeson
Mfr #
C216
Wright's #
LSN C216
Country of Origin
MEX
Specifications
C Dim
10.32"
Electrical Type
Capacitor Start Induction Run
Enclosure
DP
Full Load Efficiency
62
Frame
56
Frequency
60 Hz
HP
0.33 HP
HP2
1/3 HP
Insulation Class
B
kW
0.25kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
6.0,3.2-3.0
Rated Voltage
115/208-230
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.35
Shaft Diameter
0.63"
Speed
1725/1425
Starting Method
Description
UL recognized component listing and CSA certification ensures the product is safe for use within a variety of applications.
Premium efficiency promotes improved reliability.
Heavy-duty, rolled steel construction ensures motor durability.
Permanently lubricated, double-sealed bearings extend the lifetime of the motor.
