Leeson
1.5HP 1PH 56H ODP 1800 115/208-230V AOL
Mfr # C1160 | Wright’s # LSN C1160
1-1/2HP General Purpose Motor, 1 Phase, 56H Frame, 1725 RPM, 1 Speed, Capacitor Start Capacitor Run, 115/208-230V, DP Enclosure, Automatic Overload Protection
Contact Us For Pricing
Product Information
Brand
Leeson
Mfr #
C1160
Wright's #
LSN C1160
Country of Origin
MEX
Specifications
C Dim
11.9"
Electrical Type
Capacitor Start Capacitor Run
Enclosure
DP
Full Load Efficiency
77
Frame
56H
Frequency
60 Hz
HP
1.5 HP
HP2
1-1/2 HP
Insulation Class
B
kW
1.1kW
Material
Rolled Steel
Max Ambient
40°C
Mounting Type
Resilient Base
Number of Poles
4
Number of Speeds
1
Overload Protection
Automatic
Phase
1
Rated Current
16.4,8.4-8.2
Rated Voltage
115/208-230
Rotation
Counterclockwise/Clockwise
RPM
1725
Service Factor
1.15
Shaft Diameter
0.63"
Speed
1725
Starting Method
