Fasco
1/10HP PSC 3.3″ 3spd 1550 REV 115V 4uF DS BM
Mfr # D326 | Wright’s # FAS D326
1/10-1/20-1/25HP Fan & Blower Motor, 1 Phase, 3.3″ Frame, 1550 RPM, 3 Speed, Permanent Split Capacitor, 115V, OAO Enclosure
Contact Us For Pricing
Product Information
Brand
Fasco
Mfr #
D326
Wright's #
FAS D326
Country of Origin
MEX
Specifications
C Dim
12.7"
Electrical Type
Permanent Split Capacitor
Enclosure
OAO
Frame
3.3"
Frequency
60 Hz
HP
0.1 HP
HP2
1/10-1/20-1/25 HP
Insulation Class
B
kW
0.07kW
Material
Steel
Max Ambient
40°C
Number of Poles
4
Number of Speeds
3
Overload Protection
Thermally Protected
Phase
1
Rated Current
1.90/1.80/1.50
Rated Voltage
115
Rotation
Reversible
RPM
1550
Service Factor
1
Shaft Diameter
0.312"
Starting Method
Description
General Purpose Motor
3.3″ Diameter
Permanent Split Capacitor (PSC); Capacitor Required: 4 Mfd-370 Volts (Not Supplied with Motor)
Thermally Protected
Open Opposite Lead End End-Frame and Shell, Enclosed Lead End End-Frame, Air Over
Class B Insulation, 40°C Ambient
Sleeve Bearing
5/16″ Diameter Double Shaft with FlatϺ” Leads with Quick Connect Terminals
Extended Studs Shaft End and Opposite Shaft End
120V
